Specifications |
VC82ASE |
VF53AS |
V20D2S |
|---|---|---|---|
Product code |
FP-HP-HD-01 |
FP-HP-HD-02 |
FP-HP-HD-03 |
Engine |
2 Stroke water cooled gasoline engine |
4 Stroke water cooled gasoline engine |
2 Stroke air cooled gasoline engine |
Pump |
Single suction single stage |
Single suction single stage |
Single suction single stage |
Inlet |
4” Male round thread |
3” Male round thread |
3” Male round thread |
Outlet |
2 Nos. 2½” female instantaneous as per IS 903 / BS 336 |
2 Nos. 2½” female instantaneous as per IS 903 / BS 336 |
1 Nos. 2½” female instantaneous as per IS 903 / BS 336 |
Starting |
Electric & recoil start |
Electric & recoil start |
Electric & recoil start |
Priming |
Rotary-vane vacuum pump-oilless type |
Rotary-vane vacuum pump-oilless type |
Rotary-vane vacuum pump-oilless type |
Max outlet pressure |
145 PSI/10 kg/cm2 |
145 PSI/10 kg/cm2 |
145 PSI/8 kg/cm2 |
Control panel |
Centralised control panel for controlling pump |
Centralised control panel for controlling pump |
Centralised control panel for controlling pump |
Performance at 3m suction height |
2050 LPM @ 6 kg/cm 1800 LPM @ 8 kg/cm 1500 LPM @ 10 kg/cm |
1200 LPM @ 6 kg/cm 950 LPM @ 8 kg/cm 700 LPM @ 10 kg/cm |
650 LPM @ 5 kg/cm 400 LPM @ 7 kg/cm |
